MENNEKES Receptacle combination 9200048NF
MENNEKES Receptacle combination 9200048NF images3d

Receptacle combination 9200048NF

French/Belgian standard
  • pre-wired for installation
  • with hanging clip
  • with cable grip
  • cable entry: 1 x M 20 plugged at the top, 1 x M 20 with gland at the bottom, with 1.5 m of feeder cable H07RN-F3G1.5
  • with plug SCHUKO® or NF/plug
  • Part no.9200048NF
  • EAN4015394289456
  • Std. Pack. 3
You can manage our products in various lists in the shopping list / shopping basket area.
Please give the new list a name
  • Please enter a list name
  • The list name already exists
  • Please enter a valid list name

Technical specifications

Receptacle combination 9200048NF

French/Belgian standard 3
Connection/feeder cable
  • 1.5 m H07RN-F3G1.5 mit plug SCHUKO® or NF-plug
Protection type IP44
Enclosure material Plastic
Weight 650 g
Height 330 mm
Width 80 mm
Storage receptacle combination D

Directives

Receptacle combination 9200048NF
