MENNEKES EverBOX 9500748
MENNEKES EverBOX 9500748 images3d

EverBOX 9500748

CEE 63 A, 5 p, 400 V
CEE 32 A, 5 p, 400 V
CEE 16 A, 5 p, 400 V
SCHUKO® 16 A, 230 V
  • robust, watertight insulating enclosure, black RAL 9005
  • pre-wired for installation
  • fusing behind a transparent cover
  • Part no.9500748
  • EAN4015394283645
  • Std. Pack. 1
You can manage our products in various lists in the shopping list / shopping basket area.
Please give the new list a name
  • Please enter a list name
  • The list name already exists
  • Please enter a valid list name

Technical specifications

EverBOX 9500748

CEE 63 A, 5 p, 400 V 1
CEE 32 A, 5 p, 400 V 2
CEE 16 A, 5 p, 400 V 2
SCHUKO® 16 A, 230 V 9
Fusing
  • 1 RCD 63 A, 4 p, 0.03 A
  • 2 MCB´s 32 A, 3 p, C
  • 2 MCB´s 16 A, 3 p, C
  • 9 MCB´s 16 A, 1 p, C
Pre-fuse max. 63 A
InA 63 A
RDF 0.7
Connection/feeder cable
  • 2 m H07RN-F5G10 with CEE-plug 63 A, 5 p, 400 V
Protection type IP44
Enclosure material Plastic
Weight 20500 g
Length 560 mm
Height 340 mm
Width 350 mm
Certifications EAC
Storage receptacle combination D

Directives

EverBOX 9500748
